Furnace size

200*150*150mm

Furnace structure

Horizontal

Door opening method

Sideways

temperature

1700°C

Operating temperature

≤1600℃

Heating element

High quality silicon molybdenum rod

Temperature control method

Intelligent 30-segment PID computer programmable control

Temperature measurement

Use a little temperature control

Temperature control protection

With over-temperature and burnout alarm function

Thermocouple

Type B

Furnace material

High purity alumina polycrystalline fiber

Heating rate

0-20℃/min

Constant temperature accuracy

±1℃

Uniformity

±5℃

Furnace shell structure

Double-layer shell with air cooling system (the furnace and door plug shell are made of stainless steel)

rated power

4KW

Power supply

110V-480V 50/60HZ

Warranty

One year limited warranty with lifetime support
